What is a Chicken Feed Pellet Making Machine?
The flat die pellet mill is a feed pelleting machine that uses agricultural waste (corn stalks and poultry manure) as raw materials. The finished product is a cylindrical solid pellet with a smooth surface, high hardness, and no dust separation. Machines with capacities ranging from 50 to 1000 pellets/hour are available. Due to its many advantages, it has become the mainstream model for pelleting in small and medium-sized feed mills, biomass pellet processing plants, and farms.
Why buy a flat die pellet mill?
A flat die pellet mill isn't just about "buying a machine." Here are some simple benefits:
1. Economic Benefits: Making your own feed is much cheaper than buying finished products. The machine significantly reduces transportation and storage costs.
2. Finished Product: The pellets have moderate hardness, a smooth surface, and a forming rate of over 90%. They are sterilized and retain their nutritional value.
3. Equipment Benefits: Simple operation, stable and reliable, sustainable use, long service life, and easy maintenance.
4. Material Benefits: It is not picky about raw materials and has strong applicability.
Product Parameter Table
|
Model |
Power(kw) |
Capacity(kg/h) |
Weight(kg) |
Size(mm) |
|
WSKL-125 |
3kw |
50-80 |
75kg |
640*320*750mm |
|
WSKL-150 |
4kw |
80-120 |
95kg |
640*320*780mm |
|
WSKL-210 |
7.5kw |
250-300 |
110kg |
1000*400*1000mm |
|
WSKL-260 |
15kw |
450-600 |
135kg |
1000*500*1270mm |
|
WSKL-300 |
18.5kw |
600-700 |
220kg |
1300*510*1210mm |
|
WSKL-400 |
30kw |
800-1000 |
600kg |
1500*610*1800mm |
Requirement of material
Raw materials do not need to be ground too finely; light grinding is sufficient. The ideal moisture content is 10%–20%. Multiple raw materials can be mixed for pelleting.
This equipment primarily processes raw materials suitable for animal feed, such as cornmeal, whole grains, fishmeal, and bone meal. (For other raw materials and related questions, please contact us.)
Unique Structural Design of Chicken Feed Pellet Making Machine
1. Different feed sizes can be produced simply by changing the mold dimensions.
2. Highly wear-prone core components utilize chromium-molybdenum-titanium alloy pressure rollers, which are easy to replace.
3. The entire machine is constructed from thick-walled steel plates and features noise reduction treatment, ensuring stable operation and vibration resistance.
4. The power source can be freely selected
When we want to change the particle size, particle hardness, or the type of material being processed, or when the mold becomes damaged due to decreased friction after prolonged use, we need to replace the mold. You can refer to the text prompts in the image for mold replacement instructions.
Application Scope
Machine Application Locations
Our flat die pellet mill, with its flexibility and high efficiency, can be widely used in small and medium-sized farms, small processing plants, or combined with crushers and elevators to form a production line for feed processing plants.
Machine structure
Our company's machine adopts an integrated structure, consisting of four core parts: motor, transmission system (double universal drive shafts, automotive differential transmission), granulation unit (feed hopper, granulation chamber, etc.), and auxiliary structure (frame, casters, etc.). Each component is compactly arranged and clearly defined, balancing durability and ease of operation.
Optional machines and configurations
A flat die pellet mill can be used alone to meet small-batch pelleting needs. When paired with a crusher and elevator, it forms an automated, high-efficiency, and high-quality complete pellet production line, resulting in higher output, more stable pellet quality, and less manual labor. It is suitable for large-scale production of feed, biomass pellets, and organic fertilizer pellets.
Crusher: Ensures no clogging in subsequent pelleting processes and a higher forming rate.
Feeder: Ensures uniform and stable feeding, preventing pellet mill clogging, improving pellet forming, and ensuring more stable output.
Advantages of purchasing Lerford machines
We don't do one-off transactions. With superior machines and professional after-sales service, we have earned the trust of numerous new and existing customers. Many customers have placed multiple orders with us.
By choosing our Chicken Feed Pellet Making Machine, you will receive:
Flexible machine adaptability, suitable for everything from standalone units to production lines. We can provide corresponding models and solutions.
Pre-sales: One-on-one professional machine explanation
One-stop service, providing optimal protection for logistics, payment, etc.
After-sales: 24-hour Q&A support on weekdays, guaranteed after-sales service.
 |
 |
 |
 |
