Application scope of flat die pellet mill:
Flat die pellet mill is widely used in large, medium, and small aquaculture, grain feed factories, livestock farms, poultry farms, individual farmers, and small and medium-sized farms, farmers or large, medium, and small feed factories. flat die pellet machine is mainly suitable for rural farmers and small farms, rabbit farms. Crude fiber granulation, such as sawdust, rice husk, cotton stalk, cottonseed husk, weed, and other crop straws, and factory waste, has a low adhesion rate and is also suitable for low-temperature granulation of biological bacterial fertilizer and compound fertilizer(animal feed pellet mill).
Technical information of flat die pellet mill:
Model | WSBX-200 | WSBX-300 | WSBX-400 | WSBX-500 | WSBX-600 |
Capacity(kg/h) | 30-150 | 30-300 | 60-500 | 200-700 | 300-1300 |
Speed of principal axis(r/min) | 6000 | 3800 | 3400 | 3400 | 2500 |
Size of input granules(mm) | < 6 | < 10 | < 12 | < 12 | < 12 |
Fineness of products (mesh) | 30-150 | 30-150 | 20-120 | 20-120 | 20-120 |
Power(kw) | 4 | 5.5 | 7.5 | 11 | 15 |
Weight(kg) | 250 | 320 | 550 | 630 | 800 |
Overall size (L× W× H) (mm) | 640× 680 × 1100 | 660× 670 × 1200 | 750× 740 × 1430 | 750*750*1510 | 880× 930 × 1630 |
Overview of flat die pellet mill:
The feed pellet machine is to extrude the mixed powdery feed at one time, and the raw materials are dry in and dry out. There is no need to add water and no drying during the pelletizing process. The flat die pellet machine has high power and high output, durable, stable work, good quality, and long service life. This small pellet making machine is driven by gears, which avoids the slippage of the traditional belt drive, and the belt wears too fast. It is designed with different models and models and is a machine for farmers, feed, and straw pellet fuel.
Features of flat die pellet mill:
1. Simple structure, wide adaptability, small footprint, and low noise.
2. Powdered feed and grass powder can be pelleted without adding a little liquid, so the moisture content of the pelleted feed is basically the moisture content of the material before pelleting, which is convenient for storage(chicken feed pellet mill).
3. Chicken, duck, fish, etc. can obtain higher economic benefits than mixed powder feed.
4. The feed pellets produced from dry feed have high hardness, smooth surface, and internal ripening, which can improve the digestion and absorption of nutrients.
5. The process of particle formation can denature the pancreatic enzymes in grains and beans, reduce adverse effects on digestion, kill various parasite eggs and other pathogenic microorganisms, and reduce various worms and digestive system diseases(small poultry feed making machine).
Performance principle of flat die pellet mill:
The motor directly connected pellet machine adopts the template and the pressure roller is treated with alloy steel. Under the action of friction, the main shaft and the flat die of the feed pellet machine drive the pressure roller to rotate. The pellets are discharged from the die holes under extrusion, and the pellets are sent out of the machine through the feeding disc. The length of the pellets can be controlled by adjusting the angle of the cutter(chicken pellet maker).
How to use the flat die pellet mill:
1. After adding hyperbolic gear oil to the gearbox, it can be turned on.
2. Before working, check whether the power supply wiring and steering meet the requirements, whether the fastening screws of each part are loose, loosen the adjusting roller bolt, start the flat die pellet machine to listen for abnormal noise, and stop for inspection if there is abnormal noise.
3. When the flat die pellet machine is used, the grinding disc must be ground, and the bolts of the pressing roller are adjusted so that the gap between the pressing roller and the template is 1.5 mm.
4. Take 10 catties of compound feed and add 5 patties of vegetable oil and mix well. Start the pellet feed machine and add the oily feed. First, add a small number of pellets to be extruded and gradually increase. The extruded pellets are repeated several times before adding the mixed pellets. The powdered material works normally (note: the rotation speed of the two pressure rollers should be uniform, and it should not be too tight, otherwise the pressure roller shaft will be easily broken).
5. After work, the material in the flat die pellet mill should be removed, and the remaining material in the template hole of the pellet machine should be cleaned in a short time. The next time you use it, you can directly add the mixed feed. If the machine is stopped for a long time, you should clear the remaining material in the template hole and treat it for rust prevention(poultry pellet machine).
