Introduction of Liquid Filling Equipment
A liquid packing machine is a kind of mechanical equipment specially used to accurately fill various liquid products into packaging containers. It is widely used in many industries such as food, beverage, daily chemicals, medicine, etc. The filling machine has a simple structure and is easy to operate. It is the best choice for factories.
Structure of Liquid Filling Machine
Filling head: directly contacts the liquid and container, determines the filling accuracy and stability, and its material and design vary according to the characteristics of the filling liquid.
Conveying system: responsible for accurately conveying empty bottles to the filling position, and then smoothly removing the finished products after filling, to ensure the smooth and orderly filling process.
Measuring device: is the key to achieving accurate filling, strictly controlling the volume or weight of each filling liquid.
Control system: coordinates the operation of various components, and the operator can easily adjust the parameters on the operation interface.
Working principle
Negative pressure filling machine: First, the packaging container is evacuated to form a negative pressure environment inside, and then the liquid is pressed into the container under the action of external atmospheric pressure. This method can effectively avoid excessive contact between the liquid and the air, and the filling speed is fast. It is often used to fill various liquids, such as wine, perfume, etc.
Technical information on liquid packing equipment
|
Voltage |
AC220/110V 50/60Hz |
|||
|
Power |
20 |
50 |
20 |
50 |
|
Air pressure |
0.4-0.6Mpa |
0.4-0.6Mpa |
0.4-0.6Mpa |
0.4-0.6Mpa |
|
Filling speed |
5-25bottles/min |
10-50bottles/min |
5-25bottles/min |
10-50bottles/min |
|
Filling accuracy |
≤ ±1% |
≤ ±1% |
≤ ±1% |
≤ ±1% |
|
Adjustable Model |
5-100ml 10-300ml 50-500ml 100-1000ml 500-2500ml 1000-5000ml |
|||
Applications of Liquid Filling Equipment
Food and beverage industry
filling of products such as milk, juice, beer, soy sauce, etc.
The daily chemical industry
fills chemical products such as shampoo, shower gel, laundry detergent, etc.
Pharmaceutical industry
filling of various oral liquids, injections, eye drops, etc.
Advantages of our factory
We have a complete series of production processes and equipment to ensure stable product quality. We implement international quality management standards, establish a quality assurance system, and conduct strict inspection and testing on each equipment. We have rich service experience in domestic and foreign markets and can respond quickly to customer needs.
