Introduction of Powder Stick Pack Machine
Powder Stick Pack Machine is a fully automatic multifunctional packaging machine that can pack powder into strips. The machine has a series of automatic functions such as automatic feeding, metering, bag making, filling, sealing, printing date and finished product output. The machine can pack powders such as milk tea powder, coffee powder, matcha powder, rice paste, and medical granules, and is widely used in food, chemical, and pharmaceutical industries.
Machine parameters
|
Model |
THB4-320 |
THB4-420 |
|
Max film width |
320mm |
420mm |
|
Bag making Length |
30-150mm |
40-150mm |
|
Bag making Width |
25-145mm |
50-200mm |
|
Packing speed |
20-80bags/min |
20-80bags\min |
|
Weight |
250kg |
300kg |
|
Dimension |
750*1150*1950mm |
850*1250*1950mm |
|
Power |
220V 50/60Hz 2Kw |
2.5KW/220V 50HZ |
Powder packaging machine is a modern packaging equipment integrating mechanical, electronic, computer and automatic control technology, mainly used for quantitative packaging of various powder products. Its working principle is primarily divided into the following steps:
1. Metering and filling: The machine equipment is equipped with a precise metering device, such as a screw meter or a weighing sensor, etc., which accurately feeds the powder product from the storage hopper into the packaging bag according to the pre-set parameters to achieve quantitative filling.
2. Bag making and forming: Before filling, the packaging material (such as composite film) is automatically pulled and heat-sealed to form a packaging bag of preset size and shape. This process is completed by the bag maker to ensure that the size of each packaging bag is uniform and tightly sealed.
3. Sealing and cutting: After filling, the packaging bag is heat-sealed by an electric heating element to ensure that the powder product does not leak, and the packaging bag is cut according to the preset length by a cutting device to form an independent product package.
4. Output finished product: Finally, the finished product that has been packaged is output by the conveyor belt and enters the subsequent palletizing, boxing, and other links.
Advantages of automatic powder packing machine
1. High efficiency: The automatic powder packing machine has a high degree of automation, which can quickly pack products and improve production efficiency.
2. High precision: The machine adopts a PLC control system, which can accurately control the weight of materials and packaging.
3. High safety: The machine adopts an automated packaging procedure to reduce manual intervention, which can reduce the operating risks of personnel and improve production safety.
4. Wide range of applications: The machine is widely used to pack various powdered milk tea powder, coffee powder, medical granules, cosmetics, etc.
Application of powder packaging machine
The application range of powder packaging machine is very wide, mainly including the following industries:
1. Food industry: such as matcha powder, cocoa powder, coffee powder, tea, milk powder, food additives, etc.
2. Pharmaceutical industry: such as Chinese medicine powder, drug granules, health products, etc.
3. Cosmetics industry: such as mask powder, foundation, eye shadow, etc.
4. Pesticide industry: such as pesticide powder, insecticide, fertilizer, etc.
